Portable Vital Signs Monitor – SpO2, NIBP, TEMP & PR

The Medical Vital Signs Monitor is a compact, portable multi-parameter patient monitor designed to measure SpO2, non-invasive blood pressure (NIBP), temperature (TEMP), and pulse rate (PR).

Its 5-inch TFT colour touchscreen, rechargeable battery, intelligent alarms, data logging, and lightweight 300 g design make it suitable for patient monitoring in hospitals, wards, ambulances, operating rooms, rescue environments, and other clinical settings.

This portable vital signs monitor combines four essential physiological measurements in one compact device. Clinicians can view multiple parameters simultaneously on the colour touchscreen, helping simplify routine patient observation and monitoring.

The monitor supports adult and pediatric NIBP measurement, SpO2 monitoring, pulse-rate measurement, and optional temperature monitoring. Its portable design allows the device to be moved easily between patient-care areas.

Specifications: Medical Vital Signs Monitor

Key Benefits

• 4-parameter patient monitoring: SpO2, NIBP, TEMP, and pulse rate
• 5-inch TFT colour touchscreen for convenient operation and parameter viewing
• Compact and lightweight design weighing approximately 300 g
• Rechargeable lithium battery for portable operation
• AC/DC dual power operation
• Intelligent three-level alarm system with low, medium, and high alarm settings
• Visual and audible alarm indications
• Data logging and trend review for stored patient measurements
• 400 NIBP measurement records available for review
• 72-hour long-term trend review and 1-hour short-term trend review
• IPX1 protection against vertically falling water drops
• Designed for use in ambulances, hospitals, wards, operating rooms, helicopters, and rescue environments

Vital Signs Monitoring Functions

SpO2 and Pulse Rate Monitoring

The integrated SpO2 monitor measures blood oxygen saturation and pulse rate while displaying numerical readings and a pulse waveform.

SpO2 specifications:

• Measurement range: 0–100%
• Resolution: 1%
• Accuracy: ±2% from 70–100%
• Sensor type: Dual-wavelength LED
• Pulse rate range: 0–300 bpm
• Alarm: Visual and audible alarm

The SpO2 function provides a convenient way to monitor oxygen saturation and pulse rate as part of routine patient observation.

Non-Invasive Blood Pressure (NIBP)

The monitor provides non-invasive blood pressure measurement using the oscillometric method. Manual single measurements and automatic periodic measurements are supported.

NIBP specifications:

• Measurement method: Oscillometric
• Operation modes: Manual and automatic periodic measurement
• Parameters: Systolic blood pressure and diastolic blood pressure
• Patient types: Adults and children
• Adult pressure range: 0–300 mmHg
• Child pressure range: 0–200 mmHg
• Pressure units: mmHg / kPa
• Alarm: Audible and visual

Temperature Monitoring

The monitor supports temperature measurement through an optional temperature configuration.

Temperature specifications:

• Measurement range: 0–50°C
• Resolution: 0.1°C
• Units: °C / °F
• Alarm range: 0–50°C
• Configuration: Optional dual-channel temperature installation
• Alarm: Audible and visual

Pulse Rate Monitoring

Pulse rate is displayed alongside the other vital parameters, allowing clinicians to review multiple measurements on the same screen.

• Measurement range: 0–300 bpm
• Accuracy: ±1 bpm
• Pulse measurement: Continuous pulse monitoring
• Alarm: Audible and visual

5-Inch TFT Colour Touchscreen

The 5-inch TFT colour touchscreen provides a clear interface for viewing patient parameters and operating the monitor.

Multiple vital signs can be displayed simultaneously, including:

• Pulse rate
• SpO2
• NIBP
• Temperature
• Pulse waveform
• Alarm information
• Trend and stored data

The touchscreen interface reduces dependence on physical controls and provides direct access to monitoring functions and settings.

Intelligent Patient Alarm System

The built-in intelligent alarm system helps alert operators when monitored parameters reach configured alarm limits.

Alarm Features

• Three alarm priority levels: Low, Medium, and High
• Default and customisable alarm settings
• Audible and visual alarm indications
• Alarm latch and unlatch modes
• Alarm silence function
• Parameter-specific alarm monitoring

Alarm limits should be configured according to the patient’s clinical requirements and the healthcare facility’s monitoring protocols.

Data Logging and Trend Review

The monitor includes internal data storage and review functions for analysing previously recorded measurements.

Data Management Features

• Review of up to 400 NIBP measurements
• Playback and browsing of stored monitoring data
• Long-term trend review for up to 72 hours
• Short-term trend review for up to 1 hour
• Waveform and parameter data review

These functions can help healthcare personnel review changes in monitored vital signs over time.

Compact and Portable Design

At approximately 300 g (10.58 oz), this mini patient monitor is designed for easy transportation and single-hand handling.

Its compact form factor makes it practical for:

• Emergency medical kits
• Ambulance equipment
• Patient transfers
• Hospital wards
• Bedside monitoring
• Rescue operations
• Mobile medical applications

The device can operate from AC or DC power and incorporates a rechargeable lithium battery for mobile use.

Rechargeable Battery and Power

The monitor uses an internal rechargeable lithium battery and supports both AC and DC power operation.

• Battery capacity: Approximately 2,000–2,200 mAh as stated in the supplied specifications
• Continuous operating time: Approximately 3 hours
• Standby time: Up to approximately 6 hours
• AC/DC dual-use operation
• Rechargeable battery design

IPX1 Water Protection

The monitor has an IPX1 protection rating, providing protection against vertically falling water drops.

This basic level of liquid protection can help reduce the impact of small amounts of dripping liquid such as water, perspiration, or other incidental droplets.

Important: IPX1 does not mean the monitor is waterproof for immersion, spraying, or washing.

High-Frequency Electrosurgical Interference Protection

The monitor is designed with resistance to certain high-frequency electrosurgical interference. This feature can help reduce interference during applicable clinical procedures involving electrosurgical equipment.

Actual performance depends on the clinical environment, equipment configuration, and operating conditions.

Applications and Use Cases

The portable patient monitor is designed for a variety of professional patient-monitoring environments, including:

Hospitals and Wards

Useful for routine bedside observation of SpO2, pulse rate, blood pressure, and temperature.

Ambulances and Emergency Care

Its compact size and battery-powered operation make it suitable for mobile patient monitoring during transportation and emergency response.

Operating Rooms

The multi-parameter display and alarm functions provide convenient access to essential monitored parameters.

Rescue and Field Operations

The lightweight design supports transportation and monitoring in mobile rescue environments, including helicopter and maritime rescue applications.

Adult and Pediatric Monitoring

The supplied specifications include adult and child NIBP measurement modes. Use should always follow the device instructions, appropriate accessories, and applicable clinical protocols.

Why Choose This Portable Patient Monitor?

The Medical Vital Signs Monitor is designed to combine essential vital-sign measurements with portability and straightforward touchscreen operation. Its combination of SpO2, NIBP, temperature, and pulse-rate monitoring, rechargeable battery, data storage, trend review, and intelligent alarms makes it a practical option for healthcare environments requiring a compact monitoring solution.

Main Product Highlights

• Multi-parameter vital signs monitoring in one device
• SpO2, NIBP, TEMP, and PR measurements
• 5-inch colour touchscreen
• Approximately 300 g lightweight construction
• Rechargeable battery
• AC/DC operation
• Intelligent three-level alarm system
• NIBP measurement history
• 72-hour trend review
• IPX1 water-drop protection
• Electrosurgical interference resistance
• Portable design for emergency and clinical environments

Frequently Asked Questions

What parameters does this vital signs monitor measure?

This portable vital signs monitor measures four primary parameters: SpO2, non-invasive blood pressure (NIBP), temperature (TEMP), and pulse rate (PR).

Is this a portable patient monitor?

Yes. The device has a compact design and weighs approximately 300 g, making it suitable for portable patient-monitoring applications.

Does the monitor have a touchscreen?

Yes. It features a 5-inch TFT colour touchscreen for viewing measurements and operating the monitor.

What is the SpO2 measurement range?

The SpO2 measurement range is 0–100%, with a resolution of 1% and stated accuracy of ±2% from 70–100%.

What is the NIBP measurement range?

The stated adult NIBP range is 0–300 mmHg, while the child range is 0–200 mmHg.

Can the monitor measure temperature?

Yes. Temperature monitoring is supported with a stated measurement range of 0–50°C. The supplied specifications indicate that the temperature configuration is optional.

Does the monitor have an alarm system?

Yes. It provides low, medium, and high alarm levels, with audible and visual alarm indications. Alarm settings can be configured according to the available device functions.

How much data can the monitor store?

The supplied specifications state that the monitor can review data from 400 NIBP measurements, with up to 72 hours of long-term trend review and 1 hour of short-term trend review.

Is the monitor waterproof?

The monitor is IPX1 rated, which provides protection against vertically falling water drops. It should not be treated as an immersion- or spray-proof waterproof device.

How long does the rechargeable battery last?

The supplied specifications state approximately 3 hours of continuous operation and up to 6 hours of standby time. Actual battery performance can vary with operating conditions and measurement frequency.

Where can this vital signs monitor be used?

Potential applications include hospitals, wards, ambulances, operating rooms, helicopter rescue, maritime rescue, and other professional patient-monitoring environments, subject to applicable clinical protocols and regulatory requirements.
