The GE Datex Ohmeda TEC 7 Sevoflurane Anesthesia Vaporiser is an agent-specific anesthesia vaporiser engineered to deliver precise and reliable sevoflurane concentrations across a wide clinical flow range.Â
Designed for use with supported anesthesia machines, the TEC 7 vaporiser combines accurate anesthetic delivery, ergonomic controls, and advanced safety features to support operating rooms, surgical centres, and healthcare facilities.
The Datex Ohmeda TEC 7 Vaporiser is designed to provide consistent anesthetic output throughout a clinical flow range of 200 mL/min to 15 L/min. Its precision-calibrated control dial and advanced wick system help maintain stable sevoflurane concentrations, supporting safe and efficient anesthesia administration during surgical procedures.
Available with Easy-Fil and Funnel Fill configurations, the TEC 7 vaporiser is engineered to minimise anesthetic leakage during filling while simplifying routine maintenance and operation.
Key Benefits of the GE Datex Ohmeda TEC 7 Sevoflurane Vaporiser
Accurate Sevoflurane Administration
- Specifically calibrated for sevoflurane concentrations up to 8% v/v.
- Delivers consistent output across the full clinical flow range.
- Maintains reliable performance under standard operating conditions.
User-Friendly Design
- Large-diameter control dial with precise graduations.
- Fine adjustment increments from 0% to 1% in 0.2% steps.
- Ergonomic dial-release mechanism supports both left- and right-handed operation.
Improved Safety and Efficiency
- Agent-specific construction reduces the risk of incorrect anesthetic delivery.
- The Easy-Fil system helps minimise anesthetic spills and vapor leakage.
- Designed to reduce downtime and operating costs in healthcare environments.
Features of the TEC 7 Sevoflurane Vaporiser
- Agent-specific vaporiser designed exclusively for sevoflurane.
- Available with Easy-Fil and Funnel Fill options.
- Output consistency throughout clinical flow rates from 200 mL/min to 15 L/min.
- Precision-engineered wick system for stable vaporisation.
- Large, easy-to-turn concentration dial.
- High-visibility calibration markings.
- Compact and durable construction suitable for hospital environments.
- Fits many Datex Ohmeda anesthesia workstations and systems.
Technical Specifications
| Specification | Details |
| Brand | GE Datex Ohmeda |
| Model | TEC 7 Vaporiser |
| Agent Type | Sevoflurane |
| Equipment Category | Anaesthetic Equipment |
| Dimensions | 4.5 in (W) × 9.9 in (H) × 8.3 in (D) |
| Weight | 22 lbs |
| Operating Temperature | 18°C to 35°C (64°F to 95°F) |
| Operating Humidity | 30% to 75% RH (non-condensing) |
| Free Agent Capacity | 225 mL |
| Initial Charging Volume | 300 mL (nominal) |
| Agent Retention Volume | 75 mL (nominal) |
| Clinical Flow Range | 200 mL/min to 15 L/min |
| Sevoflurane Calibration Range | 0% to 8% v/v |
| Dial Increment (0–1%) | 0.2% steps |
| Dial Increment (1–8%) | 1% steps |
| Carrier Gas Calibration | Oxygen at 5 L/min |
| Resistance at 5 L/min O₂ | 10–15 cm H₂O |
| Filling Options | Easy-Fil and Funnel Fill |
Sevoflurane Calibration and Performance
The TEC 7 Sevoflurane Vaporiser is calibrated specifically for sevoflurane delivery up to 8% volume concentration. The concentration dial features precise graduations to help clinicians accurately adjust anesthetic output during procedures.
Calibration Details
- 0% to 1%: 0.2% increments.
- 1% to 8%: 1% increments.
- Factory calibrated using oxygen at 5 L/min and 21°C.
Accuracy
At 5 L/min oxygen flow and 21°C ±2°C:
- Accuracy tolerance: ±0.4% of delivered anesthetic concentration.
- Alternatively, ±15% of the selected dial setting, whichever is greater.
Applications and Clinical Use Cases
The GE Datex Ohmeda TEC 7 Vaporiser is suitable for a wide range of medical environments, including:
- Hospital operating rooms.
- Ambulatory surgery centres.
- Specialty surgical facilities.
- Veterinary anesthesia applications.
- Emergency and procedural anesthesia suites.
- Healthcare institutions using supported Datex Ohmeda anesthesia machines.
Frequently Asked Questions
What anesthetic agent fits the TEC 7 vaporiser?
This model is specifically engineered and calibrated for sevoflurane. TEC 7 vaporisers are agent-specific and should only be used with their designated anesthetic agent.
What is the maximum concentration setting of the Sevoflurane TEC 7 vaporiser?
The vaporiser dial is calibrated up to 8% v/v for sevoflurane delivery.
What flow rates does the TEC 7 vaporiser support?
The device is designed to maintain consistent output across a clinical flow range from 200 mL/min to 15 L/min.
What filling systems are available?
The TEC 7 Sevoflurane Vaporiser is available with Easy-Fil and Funnel Fill configurations, depending on the model variant.
Is the vaporiser easy to operate?
Yes. The vaporiser features a large concentration dial with ergonomic controls designed for both left- and right-handed users.
In which environments can the TEC 7 vaporiser be used?
The vaporiser is intended for hospitals, surgical centres, veterinary clinics, and other healthcare facilities equipped with supported anesthesia systems.
